100cm Manual Portable Satellite Dish Antenna
100cm manual portable satellite dish antennaCharacteristics:1.Meets or exceeds CCIR 580 and INTELSAT requirements2.Offset antenna;3.Light weight,small volume,high accurancy,high strength;4.High gain, Low sidelobe, high G/T rate;5.Hot-dipped zinc processed Antenna mount, with strong corrosion resista......
Send Inquiry
Product Description
Characteristics:
1.Meets or exceeds CCIR 580 and INTELSAT requirements
2.Offset antenna;
3.Light weight,small volume,high accurancy,high strength;
4.High gain, Low sidelobe, high G/T rate;
5.Hot-dipped zinc processed Antenna mount, with strong corrosion resistant ability;
6.Easy to assemble or disassemble in five minutes only with one person.
Optional:
LNB & BUC.
ELECTRICAL SPECIFICATIONS
Antenna Diameter | 1.0m | |
Band | Ku | |
| Receive | Transmit |
Operation Frequency(GHZ) | 10.95~12.75 | 13.75~14.5 |
Gain(GHZ) | 39.8+20lg(f/12.50)dBi | ≥ 41+20lg(f/14.25) dB |
3dB Beamwidth | 1.32° | 1.2° |
VSWR | 1.3:1 | 1.3:1 |
Cross-polarization | 35dB | 35dB |
Isolation,Rx to Tx,dB | 85dB | |
Power Capacity | / | 1 |
Polarization | Linear | |
Feed Interface | WR-75 | |
First Sidelobe | ≤-14dB | |
MECHANICAL SPECIFICATIONS
| Antenna diameter | 1.0m | |
| Antenna type | Offset | |
| Panel qty | 6pcs | |
Net.Weight | 15kg | |
Panel material | Carbon Fiber | |
Travel Range | Azimuth | ±45°Fine adjustment |
| Elevation | 10°~90° | |
Polarization | ±90° | |
Operational wind load | 11m/s |
| Survival wind load | 18m/s |
| Using temperature | -40°C~+60°C |
Storage temperature | -50°C~+70°C |
| Protective level | IP65 |
