New Design 3.5 Inch Full HD Digital Satellite Finder Support DVB-S/S2 MPEG-4 Standard and Free Channel Analysis

Product Description
Introduction:

356H is our new model which can Support DVB-S/S2 MPEG-4 standard and free channel analysis, it also can be easily find DVB-S and DVB-S2 signal source play, and support USB. Multi-functional design with search satellite, satellite TV display, satellite TV convert HD input, USB pictures, Music, Movie player, Record, functions etc. Users can add and revise the parameter in the satellite finder directly. Support DISEqC1.0,DISEqC1.1 multi-satellite input(the most can support 16 sate input); With DISEqC1.2, USALS satellite search window;

Advanced Features:

1.Support DVB-S Standards.
2.Fully Display DVB-S, DVB-S2, MPEG-2, MPEG-4(H.2.64/AVC) Digital Satellite Signals;
3.High quality video, audio display with HDMI output;
4.Low power consumption LED / high-resolution digital display TFT LCD;
5.Built-in satellite signal warning;
6.Easy Satellite Manager (EDIT, delete and SCAN), Edit TP;
7.USB port can use in software's upgrade and media play (such film, image, music and record etc);
8.Built-in 2600mAh Li-lon battery which can keep on working for 3 hours without external power adaptor

Specifications :

Model No.	356H
Screen Size	3.5 Inch
LCD Display	Display size:73 x 51mm(4:3display)
LCD Dots Pixels	320 x 240 (230400Pixes)
Satellite Signal Video Decoding	DVB-S/S2,MPEG-2/4 display
Satellite Signal Test	DVB-S/S2,MPEG-2/4,signal alarm & signal test.
Menu Languages	English,French,Russian;Arabic;Portuguese;;Turkish;Deutsch,Italiano;Spanish;Polish; Persian;Indonesia
LNB Connector	F type male puly : 75Ω (F)
LNB Frequency Range	950MHz-2150MHz(DVB-S/S2)
LNB Signal Level	-80~-20dBm
LNB Symbol Rate	13/18V.max400mA(DVB-S/S2)
LNB Switch Control	22KHz(Turn ON/OFF /AUTO)
LNB DiSEqC	1.0, 1.1, 1.2, USALS
Satellite Management	Edit, Add, Delete
Minimum Electric Level	About 35dBuV (noise)
Maximum Electric Level	About 90dBuV
Demodulation	QPSK/8PSK/16PSK
System Resource	SDRAM: 512M DDR2 SDRAM ; FLASH: 32MB NOR FLASH
HDMI Output	480i /480P/576i / 576P / 720P /1080i /1080P HD signal output.H.264, MPEG2 and MPEG1
Audo Decoding	MPEG-1(Lay1~3), MPEG2, AAC and HEAAC
USB Connector	USB upgrade, media player( PVR, Video, Music, Image)
Lithium Battery(Built-in)	7.4V/2200mAh
Power Charger	AC100-220V Charge 9V/1A
Unit Size	90x83x47 mm
Unit Weight	258g (including battery pack)

Standard Accessories :

DC 13.5V,1.5A Power Adaptor x1

Remote Controller x 1

Fast Line x 1

Instruction Manual x1
