Product Description
AITC P1032
P1032/WD,P1032/WF
47~1050MHz
FTTP CATV optic receiver
Product description
AITC P1032 product series, 47~1050MHz operate bandwidth, output level Vo=92dBμV ( Pin=-2dBm, PAD=0dB ), suitable for FTTP,FTTH optical fiber access network, which is a low power consumption, high performance, and excellent cost performance RFTV broadcast network ONU(Optical network unit ).
This series product adopts high sensitivity receiving tube and AITC special low noise matching circuit. Under 3.8% modulation, when transmitting in full channels and with receiving power of -8dBm, the CNR can still reach high index of 45dB. Therefore, if adopting P1032, it is only need very low optical power to reach 45dB CNR required by the user.
P1032 optical port mode with following three types optional:
P1032/NC:RFTV operating wavelength 1260~1620nm.
P1032/WF:Build-in 1310/1490 filter, RFTV operating wavelength 1550nm.
P1032/WD:Build-in CWDM,RFTV operating wavelength 1550nm, pass
wavelength 1310/1490nm, ( Link EPON,GPON ONU ).
Product feature
1. Extra low noise ( 3.8% modulate, -8dBm receiving, CNR≥ 45dB )
2. Receiving optical power within +2~ -10dBm, with excellent linearity
3. Within 47~1050MHz bandwidth, all with excellent flatness feature ( FL≤ ± 1.0dB )
4. Metal case, offer safeguard for optoelectronic sensitive devices
5. High output level, can be used by many users
6. Low power consume, high performance, high cost performance
Main application
1. FTTP
2. FTTH, FTTO
P1032/WD,P1032/WF
47~1050MHz
FTTP CATV optic receiver
Product description
AITC P1032 product series, 47~1050MHz operate bandwidth, output level Vo=92dBμV ( Pin=-2dBm, PAD=0dB ), suitable for FTTP,FTTH optical fiber access network, which is a low power consumption, high performance, and excellent cost performance RFTV broadcast network ONU(Optical network unit ).
This series product adopts high sensitivity receiving tube and AITC special low noise matching circuit. Under 3.8% modulation, when transmitting in full channels and with receiving power of -8dBm, the CNR can still reach high index of 45dB. Therefore, if adopting P1032, it is only need very low optical power to reach 45dB CNR required by the user.
P1032 optical port mode with following three types optional:
P1032/NC:RFTV operating wavelength 1260~1620nm.
P1032/WF:Build-in 1310/1490 filter, RFTV operating wavelength 1550nm.
P1032/WD:Build-in CWDM,RFTV operating wavelength 1550nm, pass
wavelength 1310/1490nm, ( Link EPON,GPON ONU ).
Product feature
1. Extra low noise ( 3.8% modulate, -8dBm receiving, CNR≥ 45dB )
2. Receiving optical power within +2~ -10dBm, with excellent linearity
3. Within 47~1050MHz bandwidth, all with excellent flatness feature ( FL≤ ± 1.0dB )
4. Metal case, offer safeguard for optoelectronic sensitive devices
5. High output level, can be used by many users
6. Low power consume, high performance, high cost performance
Main application
1. FTTP
2. FTTH, FTTO
| Performance | Index | Supplement | ||
| Optic feature | CATV work wavelength | (nm) | 1260~1620 | P1032/NC |
| 1540~1560 | P1032/WF, P1032/WD | |||
| Input wavelength | (nm) | 1310, 1490/1550 | ||
| Pass wavelength | (nm) | 1310, 1490 | ||
| Channel Isolation | (dB) | ≥ 40 | 1550 & 1490nm | |
| Responsibility | (A/W) | ≥ 0.85 | 1310nm | |
| ≥ 0.9 | 1550nm | |||
| Receiving power | (dB) | +2 ~ -10 | Analog TV | |
| +2 ~ -16 | Digital TV | |||
| Optical return loss | (dB) | ≥ 55 | ||
| Optical fiber connector | SC/APC | P1032/NC, P1032/WF | ||
| LC/APC | P1032/WD | |||
| RF feature | Work bandwidth | (MHz) | 47 ~ 1050 | |
| Flatness | (dB) | ≤ ± 1.0 | ||
| Output level | (dBμ V) | 92 | Pin=-2dBm (PAD=0dB) | |
| Output level adjust | (dB) | 0 ~ 18 | MGC | |
| Return loss | (dB) | ≥ 14 | 47 ~ 1050MHz | |
| Output impedance | (Ω ) | 75 | ||
| Output port number | 1 | |||
| RF tie-in | F-Female | |||
| Analog TV Link feature | Test channel | CH | 59CH (PAL-D) | NTSC/80CH |
| OMI | (%) | 3.8 | ||
| CNR1 | (dB) | 54.6 | Pin=-2dBm | |
| CNR2 | (dB) | 46.8 | Pin=-8dBm | |
| CTB | (dB) | ≤ -70 | Pin=-2dBm | |
| CSO | (dB) | ≤ -65 | Pin=-2dBm | |
| HUM | (dB) | ≤ -60 | ||
| Digital TV Link feature | Test channel | < 10 CH | Analog | |
| Digital QAM | 47-862MHz | |||
| MER | (dB) | 38 (Remark1) | Pin = -10dBm | |
| 34.0 | Pin = -15.0dBm | |||
| BER | (dB) | < 1.0E-9 | Pin: -20.0~+2.0dBm | |
| General feature | Power supply | (V) | DC+12V | ± 1.0V |
| Power Consume | (W) | ≤ 3 | +12VDC, 260mA | |
| Work temp | (º C) | -20 ~ +50 | ||
| Storage temp | (º C) | -40 ~ 85 | ||
| Work relative temp | (%) | 5 ~ 59 | ||
| Size | (mm) | 59× 98× 23 | (W)× (D)× (H) | |
