Nickel-Plated Metal Case Connectorrj45 8p8c
Nickel-plated Metal Case CAT6 FTP Network cable connector Standard .ANSI/TIA/EIA 568 A | B |Application ......
Send Inquiry
Product Description
Nickel-plated Metal Case CAT6 FTP Network cable connector
Standard .
ANSI/TIA/EIA 568 A | B |
Application .
Widely used in wring solutions for company banks,hotels,schools,factories,communities and business building
specification .
Crystal head material: polycarbonate( PC)
shield material: Nickel-plated Metal Case /gold plated copper case
Contact: three-jaw
Reinforced shrapnel with parallel design and resistance to bending
Electrical performance .
250V AC max at 2 amps
Dielectric with standing 500volts AC
Insulation Resistance: 00megaohms
Termination Resistance: 35megaohms
Mechanical Property .
Cable-to-Plug tensile strength-20LBs(89N)min
Durability:500 mating cycles
Operation Temperature: -20ºC~+60ºC
SUPERLINK® CAT5E UTP RJ45 NETWORK CABLE CONNECTOR
Packing (100 or 1000pcs/bag)
Packing (10000pcs/carton)
Standard .
ANSI/TIA/EIA 568 A | B |
Application .
Widely used in wring solutions for company banks,hotels,schools,factories,communities and business building
specification .
Crystal head material: polycarbonate( PC)
shield material: Nickel-plated Metal Case /gold plated copper case
Contact: three-jaw
Reinforced shrapnel with parallel design and resistance to bending
Electrical performance .
250V AC max at 2 amps
Dielectric with standing 500volts AC
Insulation Resistance: 00megaohms
Termination Resistance: 35megaohms
Mechanical Property .
Cable-to-Plug tensile strength-20LBs(89N)min
Durability:500 mating cycles
Operation Temperature: -20ºC~+60ºC
SUPERLINK® CAT5E UTP RJ45 NETWORK CABLE CONNECTOR
Packing (100 or 1000pcs/bag)
Packing (10000pcs/carton)
Number | Box size Weight | Color | |
| Color box /conton | |||
| 100 or1000pcs/bag | |||
| 10000pcs/carton | 46*36*25cm | ||
| 100pcs/bag 10000pcs/carton | |||
