1550nm Fiber Optica Amplifier EDFA
1550nm fiber Optica amplifier EDFA Set and operation Device type ProjectFWA-1550HOperating wavelength (nm)1540~1565Input optical power(dBm)-10~+10Nominal input optical power (dBm)+3Noise figure (dB) (+3 dBm,@1550nm......
Send Inquiry
Product Description
1550nm fiber Optica amplifier EDFA
Set and operation
More information
Q1: Where is your company located?
A: Our company is located in Hangzhou City,Zhejiang Province, China. All our clients,from home or abroad are warmly welcomed to visit us!
Q2: Do your products safe enough?
A: Our products meet with the certificate of CE,ISO & Rosh. Our products are made according to the standard of the market in our clients. They're all in superior quality & competitive price. You can rest assure that they are safe enough.
Q3: How long does your warranty provide?
A: We usually provide you a 2-year warranty after the date we sold under a normal usage.
Q4:What's your payment terms?
A:T/T, Western Union, Money Gram
Q5:What's your delivery time?
A: Around 8 working days after get payment in account ( or pre-payment)
Q6:Can you accept OEM?
A:Yes. We would accept OEM&ODM.
If you have another question, please feel free to contact me directly as below:
Hangzhou Fullwell Optoelectronic Equipment Co., Ltd
Add:A2-1305,Qimeng Science & Innovation Park,No.1899,Gudun Road,Hangzhou, China
Contact person: Leo Yao
"Design and manufacture the most reliable and efficient FTTH CATV equipment products in the industry."
Set and operation
| Device type Project | FWA-1550H |
| Operating wavelength (nm) | 1540~1565 |
| Input optical power(dBm) | -10~+10 |
| Nominal input optical power (dBm) | +3 |
| Noise figure (dB) (+3 dBm,@1550nm) | 5.0~6.0 |
| Gain flatness(dB) | <±0.3 |
| Stability of output optical power (dB) | <±0.5 |
| Polarization sensitivity (dB) | <0.2 |
| Polarization modal dispersion (ps) | <0.5 |
| Optical connector(IN/OUT) | SC/APC |
| Pump work quantity (N) | 2 |
| Saturated output power (dBm) | >=26dBm each |
| Power supplies (Vac) | 115~265(draw-out plug) |
| Power supplies (Vdc) | 48(draw-out plug)-optional |
| Operating temperature (ºC) | 0~50 |
| Size (mm) | 88×482.6×387 |
