Product Description
ISO9001 Factory SFU HGU high quality 1ge zte f601 huawei ONU
OFSG511
1GE Ethernet ports GPON ONU for FTTH solution
Description:
OFSG/E511 is GPON ONU terminal devices designed for fulfilling FTTx and triple play service demand of fixed network operator or cable operators.This box is based on the stable and mature Gigabit GPON technology, which has high ratio of performance to price. It is highly reliable and easy to maintain, with guaranteed QoS for different service.
Definition of indicator LED
l Plug and play, features auto-detecting, auto-configuration, and auto firmware upgrade, etc.
l Completely compatible with GPON international standard IEEE802.3ah/802.3-2005
l Support China Telecom GPON CTC3.1 standard and expand OAM
l Support DBA reporting mechanism request
l Support OAM (Link, Test, Loop back)maintenance function defined IEEE802.3ah
l Support the remote upgrade and download
l Support to save configured parameters if power down
l Support to configure the work mode at the user port
l Support MDI-MDIX automatic-detection at the user port.
l Support access authentication based on serial number
l Support access authentication based on MAC address
l Support 802.1Q VLAN
l Support rich QinQ VLAN functions and IGMP Snooping
l Support traffic rule to modify the related priority.
l Support to restore the factory settings
l Support the remote reset and reboot
l Support dying gasp outage alarm
l Fully compatibility with OLT based on Broadcom/PMC/Cortina chipset.
Basic Characteristics
Tech parameters | description |
Up-link interface | 1 GPON interface,SC single mode single fiber RX 2.488 Gbits/s rate and TX 1.244 Gbits/s rate Fiber type:SC/UPC Optical power:0~4 dBm Sensitivity:-28 dBm safety: ONU authentication mechanism |
Wavelength(nm) | TX 1310nm,RX 1490nm |
Fiber connector | SC/UPC connector (SC / APC optional) |
Down-link data interface | 1*10/100/1000M auto-negotiation Ethernet interface, RJ45 interface |
Indicator LED | 4 pcs |
DC supply interface | input+12V 0.5A |
Power | ≤5W |
Operating temperature | -5~+55ºC |
Humidity | 10~85%(non-condensation) |
Storage temperature | -30~+70ºC |
Dimension(MM) | 85*85*28mm(mainframe) |
Weight | 0.24Kg(mainframe) |
