72cores FTTH Outdoor Polo Mount Fiber Optic Joint Closure
TGJS302 Inline Type Fiber Optical Splice ClosureInline Closure provide space and protection for fiber optic cable splicing and joint. They can be mounted aerial, duct, or for pole mounting applications. They are designed to be waterproof and dust proof. They can be used in temperature ranging from -......
Send Inquiry
Product Description
TGJS302 Inline Type Fiber Optical Splice Closure
Inline Closure provide space and protection for fiber optic cable splicing and joint. They can be mounted aerial, duct, or for pole mounting applications. They are designed to be waterproof and dust proof. They can be used in temperature ranging from -40°C to 85°C, can accommodate 70 to 106 kpa pressure and the case are usually made of high tensile construction plastic.| Inline Closure TGJS-302 | |
| Material | 100% NEW PC(Polycarbonate) |
| Size | 335*179*85mm |
| Cable Ports | 3 In / 3 Out |
| Material | 100% New PC |
| Max Capacity | 72FO=24FO*3Trays |
| Splice Tray | 24FO/Tray ABS Material |
| Net Weight | 2.2KG |
| Accessories | 24*Protecting Sleeves, |
| Installation Way | Aerial or Wall-Moubtedor Pole-Mounting |
APPLICATION
Suitable for ribbon and non-ribbon fibersAerial
Cable duct
Direct burial
Wall-mounted
PRODUCT FEATURES
Reliable gasket sealingEasy installation with no special tool required
Re-enterable with no re-entry kit needed
High compressive strength
