Dual Power 1 Way Output 1550 Optical Laser Transmitter

Product Description

Items			Parameter	Remark
Optic Parameters	Operating wavelength	(nm)	1550±10
	Output power	(dBm)	2×7	1×5,1×6,1×7, 1x8,1x9, 2×3,2×4,2×5 , 2×6 , 2×7
	Return loss	(dB)	≥52
	Optical fiber connector		SC/APC	Optional SC/APC,FC/APC
RF Parameters	Bandwidth	(MHz)	45-862
	Input level	(dBmV)	23±5	AGC
	Flatness	(dB)	≤±0.75	45~862MHz
	Return loss	(dB)	>16	45~750MHz
	Input Impedance	(Ω)	75
Link Parameters	Channels		PAL-D/60ch
	CNR	(dB)	≥52	65Km fiber,Receive0dBm
	CTB	(dB)	≤-65
	CSO	(dB)	≤-65
	SBS	(dB)	≥16.0	13,16,18dB adj.
General Parameters	NM interface		RJ45, R232
	Power	(V)	90~265	Optional -48VDC
	Power consumption	(W)	≤50
	Working Temp	(ºC)	0~50	Automatically casing temp control
	Storage Temp	(ºC)	-20~85
	Operating relative humidity	(%)	5~95
	Size	(")	19×14.5×1.75	(W)x(D)x(H)

FWT-1550ES -1×5    (one output,≥5dBm)
FWT-1550ES -1×6    (one output,≥6dBm)
FWT-1550ES -1×7    (one output,≥7dBm)
FWT-1550ES -1×8    (one output,≥8dBm)
FWT-1550ES -1×9    (one output,≥9dBm)
FWT-1550ES -2×3   (two outputs,≥3dBm)
FWT-1550ES -2×4   (two outputs,≥4dBm)
FWT-1550ES -2×5   (two outputs,≥5dBm)
FWT-1550ES -2×6   (two outputs,≥6dBm)
FWT-1550ES -2×7   (two outputs,≥7dBm)
Dual Power 1 Way Output 1550 Optical Laser Transmitter

FAQ

1. What are your terms of payment?

Usually, we can accept T/T, PayPal, and Western Union. You can select the terms of payment which is more convenient for you.

2. What about the lead time?

Usually, if there is the stock of goods, we will deliver the goods within 3~5 work days after we receive the payment.

3. How about the shipping?

Usually, we will deliver the goods via International Express like FedEx, DHL, TNT, and UPS and so on. Door to door delivery service will be provided.

4. How can I place an order?

(1) The agreement is achieved on the product price and product specifications.

(2) We make proforma invoice for your confirmation.

(3) When you agree on the proforma invoice, you make the payment.

(4) We deliver the goods after we receive your payment.

5. Can you do OEM for us?

Yes. If there is a certain order quantity, we can do OEM including printing, logo, and customized model for you.

6. What are the advantages of your products?

A. Good quality and competitive prices.

B. Strict quality control during production process.

C. Professional operations in processes of production, sales, assembling, packaging, and shipping.

D. Good after-sale service. Professional online technical support can be provided. Moreover, if there is any problem with the goods, we will help to solve the problem or provide replacement of the goods.

Dual Power 1 Way Output 1550 Optical Laser Transmitter
