Single Sc 10/100Mbps Unmanaged Media Converter Sm 60km
Single Sc 10/100Mbps Unmanaged Media Converter Sm 60kmFiber optic media converter---Overcome the distance limitations of traditional network cables with fiber media convertersThese converters connect different types of network cabling and help you extend networks between buildings and over longer di......
Send Inquiry
Product Description
Single Sc 10/100Mbps Unmanaged Media Converter Sm 60km
Fiber optic media converter---Overcome the distance limitations of traditional network cables with fiber media converters
These converters connect different types of network cabling and help you extend networks between buildings and over longer distances.
Description:
The MC series fiber optic media converters are a full line of products that transparently connects copper network devices to fiber optic network cabling.
Fiber media converter support Ethernet and Gigabit Ethernet twisted-pair electrical signal to the 100Base-FX and 1000Base-FX light signal interconversion. It expands the network transmitting range limit from the copper wire 100meters to 2km (MM optical fiber),120km (SM optical fiber).
Feature:
Compliant with IEEE802.3 and IEEE802.3u 100BaseTX/FX standards
Extends standard Ethernet cable limits
Autosensing MDI/MDIX Crossover for Network Port
Fully transparent to the network
Supports any network device, including IP cameras
Easy to install, no set up required.
No MAC or IP addressing required.
LED indicators for network signals, link status and power
Technical specification
Fiber optic media converter---Overcome the distance limitations of traditional network cables with fiber media converters
These converters connect different types of network cabling and help you extend networks between buildings and over longer distances.
Description:
The MC series fiber optic media converters are a full line of products that transparently connects copper network devices to fiber optic network cabling.
Fiber media converter support Ethernet and Gigabit Ethernet twisted-pair electrical signal to the 100Base-FX and 1000Base-FX light signal interconversion. It expands the network transmitting range limit from the copper wire 100meters to 2km (MM optical fiber),120km (SM optical fiber).
Feature:
Compliant with IEEE802.3 and IEEE802.3u 100BaseTX/FX standards
Extends standard Ethernet cable limits
Autosensing MDI/MDIX Crossover for Network Port
Fully transparent to the network
Supports any network device, including IP cameras
Easy to install, no set up required.
No MAC or IP addressing required.
LED indicators for network signals, link status and power
Technical specification
| Warranty Information | |
| Warranty | 2 years |
| Hardware | |
| Industry Standards | IEEE 802.3 10BASE-T |
| IEEE 802.3u 100BASE-FX | |
| IEEE 802.3ab 100BASE-T | |
| PoE | No |
| WDM | No |
| Performance | |
| Fiber Operating Mode | Single fiber |
| Fiber Type | Single mode |
| Max Transfer Distance | 60 KM |
| Compatible networks | 10/100Mbps |
| MTBF | >5,0000 Hours at 25degree |
| Maximum data transfer rate | 155M |
| Connector(s) | |
| Local Unit Connectors | 1 - RJ-45 Female |
| 1 - SC simplex | |
| Indicators | |
| LED Indicators | 1 - Speed rate |
| 1 - Half-duplex | |
| 1 - Copper port Link/Act | |
| 1 - Fiber Port Link/Act | |
| 1 - Power | |
| 1 - 10/100 | |
| Power | |
| Center Tip Polarity | Positive |
| Input current | 1 A |
| Input voltage | 100 - 240 AC |
| Output current | 2 A |
| Output voltage | 5 DC |
| Plug type | N |
| Power Source | AC Adapter Included |
| Environmental | |
| Operating Temperature | 0°C to 50°C (32°F to 122°F) |
| Storage Temperature | -10°C to 70°C (14°F to 158°F) |
| Color | Black / Grey /Brown |
| Enclosure Type | Steel |
| Included in Package | 1 - 155M Ethernet Fiber Media Converter 1 - British plug |
| Transceiver Unit | |
| IEEE: | 802.3, 802.3u |
| Ethernet: | 1000BaseT (1) RJ45 Jack |
| Fiber: | 1000BaseFX (1) SC Duplex Connector |
| Wavelength: | 850T/850R |
| Typical Distance: | See Ordering Information |
| Link Budget: | 19.0 dB |
| External Power Supply: | 5V DC @ 1.0A |
| Power Consumption: | 5 W |
| Operating Temperature: | 0 - 70 degrees centigrade |
