8/16/24 in 1 MPEG-4 Avc/H. 264 HDMI Input Digital Encoder
Digital Headend 4 in 1 MPEG-4 AVC/H.264 HDMI Digital EncoderProducts details:Description:The encoder is a professional HD audio & video encoding and multiplexing device with powerful functionality. It has 4 channel HDMI input interfaces, supporting MPEG4AVC/H.264 High Profile code format. This d......
Send Inquiry
Product Description
Digital Headend 4 in 1 MPEG-4 AVC/H.264 HDMI Digital Encoder
Products details:
Description:
The encoder is a professional HD audio & video encoding and multiplexing device with powerful functionality. It has 4 channel HDMI input interfaces, supporting MPEG4AVC/H.264 High Profile code format. This device can simultaneously encode 4 channel HD programs; moreover, it has an ASI input and can multiplex the input TS with the 4 encoded SPTS to generate a MPTS output. Also, the PSI/SI information can be inserted into MPTS output. In conclusion, its high integrated and cost effective design makes the device widely used in varieties of digital distribution systems such as CATV digital head-end, satellite and terrestrial digital TV, etc.
Feature:
Products details:
Description:
The encoder is a professional HD audio & video encoding and multiplexing device with powerful functionality. It has 4 channel HDMI input interfaces, supporting MPEG4AVC/H.264 High Profile code format. This device can simultaneously encode 4 channel HD programs; moreover, it has an ASI input and can multiplex the input TS with the 4 encoded SPTS to generate a MPTS output. Also, the PSI/SI information can be inserted into MPTS output. In conclusion, its high integrated and cost effective design makes the device widely used in varieties of digital distribution systems such as CATV digital head-end, satellite and terrestrial digital TV, etc.
Feature:
- H.264/AVC High Profile Level 4.0 video encoding support, advanced video pretreatment algorithm
- Audio MPEG1 Layer 2, AAC(optional)
- 4 channel HDMI inputs, 1 ASI input supports multiplexing
- Real- time effective output bit-rate monitoring
- 720P, 1080I HD video format support
- MPTS ASI output
- MPTS over UDP unicast/multicast output
- LCD / keyboard operating
- NMS support
- Work Shop:
- Our Team:
| Input | 12 HDMI inputs ( 8//16/20/24 input optional) | |||
| Video | Resolution | input | 1920×1080_60P, 1920×1080_60i, 1920×1080_50P, 1920×1080_50i, 1280×720_60P, 1280×720_50P, 720×576_50i,720×480_60i, | |
| output | 1920×1080_30P, 1920×1080_25P, 1280×720_30P, 1280×720_25P, 720×576_25P,720×480_30P, | |||
| Encoding | MPEG-4 AVC/H.264 | |||
| Bit-rate | 1Mbps~13Mbps each channel | |||
| Rate Control | CBR/VBR | |||
| GOP Structure | IP…P (P Frame adjustment, without B Frame ) | |||
| Audio | Encoding | MPEG-1 Layer 2 | ||
| Sampling rate | 48KHz | |||
| Resolution | 24-bit | |||
| Bit-rate | 64kbps,128Kbps,192kbps,224kbps,256kbps, 320kbps,384kbps | |||
| Multiplexing | Maximum PID Remapping | 180 input per channel | ||
| Function | PID remapping ( automatically or manually) | |||
| Accurate PCR adjusting | ||||
| Generate PSI/ SI table automatically | ||||
| Stream output | 12 SPTS IP or 1MPTS output over UDP/RTP, 1*1000 Base-T Ethernet interface ASI output(optional) as copy of MPTS | |||
| System function | Network management(WEB) | |||
| Chinese and English language | ||||
| Ethernet software upgrade | ||||
| Miscellaneous | Dimension(W×L×H) | 482mm×410mm×44mm | ||
| Approx weight | 8kg | |||
| Environment | 0~45ºC(work);-20~80ºC(Storage) | |||
| Power requirements | AC 110V± 10%, 50/60Hz, AC 220 ± 10%, 50/60Hz | |||
| Power consumption | 70W | |||
