4G/Lte Omni Ceiling Mount Antenna Indoor Coverage Antenna
Applications:1,Indoor distributed antenna system.Features:1,Light weight, small size, wide bandwidth;2,Anti-ultraviolet ABS radome. Electrical SpecificationsFrequency Range698-9601710-2700MHzVSWR≤1.8≤1.5Gain2.5dBi3.5dBiHorizontal beam width360°360°Vertical beam width65&......
Send Inquiry
Product Description
Applications:
1,Indoor distributed antenna system.
Features:
1,Light weight, small size, wide bandwidth;
2,Anti-ultraviolet ABS radome.
| Electrical Specifications | ||
| Frequency Range | 698-960 | 1710-2700MHz |
| VSWR | ≤1.8 | ≤1.5 |
| Gain | 2.5dBi | 3.5dBi |
| Horizontal beam width | 360° | 360° |
| Vertical beam width | 65° | 55° |
| Polarization | Vertical | |
| Input Impedance | 50Ω | |
| Maximum input power | 50W | |
| Lightning protection | DC Ground | |
| Mechanical Specifications | ||
| Input connector type | N-K | |
| Dimensions | Ø165×100mm | |
| Antenna weight | 0.3kg | |
| Radiating Element Material | AI | |
| Radome material | ABS | |
| Radome color | White | |
| Operating temperature | -40°C to +65 °C | |
FAQ
Q: Can I get one sample?
A: Yes, sample is available.
Q: Have GNSS Antenna 100% assembles well in stock?
A: No, all GNSS antenna will be newly assembled according to your orders including the samples.
Q: What's the delivery time?
A: 3-5 working days for the sample, 10-15 working days for quantity below 5K,.
Q: Could i use my own LOGO or design on goods?
A: Yes, customized logo and design on mass production are available.
Q: What's the payment term?
A:T/T, Paypal, Western Union etc.
Q:May I visit your company?
A: Sure, welcome any time.
Q: How long of the warranty?
A: one year for antennas and half a year for assembly cables and connectors
